Pressure

9200 Series Pressure Meters

ETI-825905

Brand: ETI

add to wishlist?
Send Wishlist

Product Details:

9200 Series Pressure Meters for measuring positive & negative differential pressure

  • robust water resistant case offering IP65 protection
  • 11 selectable units of measurement
  • 4 models available - ±5 to ±75 psi
  • automatic temperature compensation

This new range of four industrial differential pressure meters offer high accuracy, performance and repeatability. The pressure meters allow the user to indicate the positive and negative differential pressure over the range of ±5, ±15, ±30 or ±75 psi.  All instruments feature over pressure protection to at least twice the measuring capacity. These easy to use pressure meters are ideal for measuring non-corrosive gauge or differential air/gas pressure in a wide variety of industries.

The 9205 model is supplied with two 500 mm long x 6 mm ID connection hoses with batteries and operation manual.

The 9215,9230 & 9275 come with two 300 mm long by 4 mm ID hoses, batteries and operating manual.


CatalogManual;
